| Analog Video Input |
4 Channels |
| HDTVI Input |
8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps Note: The 8 MP signal input is only available for channel 1. |
| AHD Input |
5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| HDCVI Input |
4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| CVBS Input |
PAL/NTSC |
| IP Video Input |
1 Channel |
| IP Video Support |
Up to 6MP |
| Audio input |
1-Ch RCA |
| Video Compression |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Audio Compression |
G711.u |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 ? 576, NTSC: 704 ? 480 |
| HDMI/VGA Output |
1920 ? 1080 / 60 Hz,1280 ? 1024 / 60 Hz, 1280 ? 720 / 60 Hz, 1024 ? 768 / 60 Hz |
| Encoding Resolution |
For 4 MP stream access: 4 MP lite@15 fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps |
| Video bit Rate |
2 |
| Audio Output |
1-Ch RCA |
| Audio bit Rate |
64 Kbps |
| Dual Stream |
Supports |
| Stream Type |
Video, Video & Audio |
| 1Synchronous Playback |
4 Channels |
| Remote Connections |
32 |
| Network Protocols |
1 |
| SATA |
8 HDD |
| HDD |
Up to 8 TB |
| Network Interface |
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| USB Interface |
2 x USB 2.0 |
| Serial interface |
1 X RS485 Half Duplex |
| Two Way Audio Input |
1-Ch RCA |
| Power Supply |
< 10 W |
| Power Consumption without HDD |
1 |
| Dimensions (W x D x H) |
< 1.16 kg |
| Weight (without HDD) |
? 1.16 kg |
| Video Input Channels |
4 Ch |
| Support Recording Resolution |
3MP/5MP/8MP |
| Hybrid IP Video Input |
2 Ch |
| Incoming Bandwidth |
32 Mbps |
| Full Channel Recording Resolution on MP Analysis |
8 MP@8 fps |
| Full Channel Recording Resolution up to fps |
2 MP@25fps |
| HDD Interface |
1 |
| Audio over Coaxial and IP |
Yes |
| RCA Audio in/out |
1/1 |
| Acusense Hikvision |
Yes |
