Ubiquiti LBE-5AC-Gen2 Passive PoE LiteBeam Outdoor 5GHz 23dBi WiFi PoE Access Point

104.16€
138.88€
LBE-5AC-Gen2

Description

Passive PoE The Ubiquiti LBE-5AC-Gen2 LiteBeam Outdoor 5GHz 23dBi WiFi PoE Access Point is the latest in a generation of airMAX and is designed to integrate a separate WiFi radio for fast and easy setup using a mobile device.

The Ubiquiti LBE-5AC-Gen2 LiteBeam Outdoor 5GHz 23dBi WiFi PoE Access Point features InnerFeed technology which integrates the radio into the feedhorn of an antenna, so there is no need for a cable and improves performance.

Providing high throughout and innovative form factor for versatile deployment.

Features

  • InnerFeed technology which integrates the radio into the feedhorn of an antenna.
  • High performance and innovative mechanical design for cost-effective deployment.
  • UMobile app provides instant accessibility to the airOS configuration interface.
  • Integrates separate WiFi radio for fast and easy setup using mobile device.
  • Features enhanced protection against power surges and a more robust mount.
  • Built-in bubble-level coupled with mounting system enabling quick and easy alignment.
  • Incorporates power wireless features such as selectable channel width and WPA2 security.
  • Features a two-mount system that provides adjustment flexibility and versatile mounting.
Specifications
Dimensions 358 x 271.95 x 272.5 mm (14.09 x 10.71 x 10.73")
Weight  Without Mount: 800 g (1.76 lb)
With Mount: 980 g (2.16 lb)
Power Supply 24V, 0.3A Gigabit PoE Adapter (Included)
Max. Power Consumption 7W
Power Method Passive PoE (Pairs 4, 5+; 7, 8 Return)
Supported Voltage Range 24V ± 10% Gain 23 dBi
Networking Interface (1) 10/100/1000 Ethernet Port
Processor Specs MIPS 74Kc Memory 64 MB DDR2
LEDs Power, Ethernet
Channel Sizes PtP Mode: 10/20/30/40/50/60/80 MHz
PtMP Mode: 10/20/30/40 MHz
Enclosure Characteristics Reflector (SGCC 0.6T) / Plastic: PC
Mounting Pole-Mounting Kit (Included)
Wind Loading 275 N @ 200 km/h (61.8 lbf @ 125 mph)
Wind Survivability 200 km/h (125 mph)
ESD/EMP Protection ± 24 kV Contact / Air
Operating Temperature -40 to 70° C (-40 to 158° F)
Operating Humidity 5 to 95% Noncondensing
Certifications CE, FCC, IC

  • LBE-5AC-Gen2 / 10187_LBE-5AC-Gen2.pdf) (, 6483.73 kb)
