The Ubiquiti UniFi Directional Dual-Band Antenna UMA-D is an optional mesh antenna designed to work with the UniFi AC Mesh AP, model UAP-AC-M.
Description
The Ubiquiti UniFi Directional Dual-Band Antenna UMA-D is an optional mesh antenna designed to work with the UniFi AC Mesh AP, model UAP-AC-M. With dual-band support, the UMA-D expands range coverage and provides customised pattern shaping.
It features a high efficiency directional radiation pattern with dual polarity and is optimised for 802.11ac.
Ubiquiti UniFi UMA-D Key Features Can be used indoors or outdoors Dual-Band, Dual-Polarity Optimized for 802.11ac High Efficiency Directional Radiation Pattern Three-Axis Ball Joint Mount for Precise Aiming Compatible with the UAP-AC-M.
|
Specifications |
|
| Dimensions | 201.3 x 128.0 x 32.5 mm |
|
Weight |
-480 g (16.93 oz) -400 g (14.11 oz) |
| Enclosure | Outdoor UV Stabilized Plastic |
| RF Connections | (2) RP-SMA |
| Supported Frequency Range | 2.4 - 2.5 GHz, 5.1 - 5.9 GHz |
| HPOL Beamwidth -2.4 GHz -5 GHz |
-90° -45° |
|
VPOL Beamwidth |
-90° -45° |
| Elevation Beamwidth -2.4 GHz -5 GHz |
|
| Maximum VSWR | 2.5:1 |
| Polarization | Dual-Linear |
| Cross-Pol Isolation -2.4 GHz -5 GHz |
-25 dB -30 dB |
|
Antenna Gain |
-10 dBi -15 dBi |
| Mounting | Wall/Pole (Kits Included) |
