Description

The 16-Port Gigabit Desktop Switch, model TEG-S17D, provides high bandwidth performance, ease of use, and reliability. Boost office network efficiency and eliminate network congestion with gigabit speeds and a total switching capacity of 32Gbps with full-duplex mode. A built-in universal power supply reduces cable clutter, and diagnostic LEDs help with network troubleshooting. Plug and play this sturdy metal switch for reliable high-speed network connectivity.

Features

16 x Gigabit RJ-45 ports
Sturdy metal desktop switch
Built-in power supply
32Gbps forwarding capacity
Fanless design
1U rackmount brackets included
NDAA / TAA compliant (U.S. and Canada only)
Lifetime Warranty*

Specifications
Standards	IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3ab
Device Interface	16x Gigabit ports LED indicators
Data Transfer Rate	Ethernet: 10Mbps (half duplex), 20Mbps (full duplex) Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex) Gigabit: 2000Mbps (full duplex)
Performance	Switching Capacity: 32Gbps RAM Buffer: 512KB MAC Address Table: 8K entries Forwarding Rate: 23.8Mpps (64-byte packet size) Jumbo Frames: 9KB
Special Features	Rack Mountable
Power	Internal power supply: 100 – 240V AC, 50/60 Hz, 0.2A Max. Consumption: 9.19W
Fan/Acoustics	Fanless design
MTBF	1,1121,721 hours
Operating Temperature	0° – 40° C (32° – 104° F)
Operating Humidity	Max. 90% non-condensing
Dimensions (L x W x H)	216 x 132 x 43mm (8.5 x 5.20 x 1.69 in.)
Weight	414g (14.6 oz.)
Certifications	FCC CE ETL
Warranty	Lifetime Warranty
