Feature-rich IP desktop phone with superior voice quality
Description
The Snom D717 is a professional desktop phone and a cost-effective entry-level device into the world of VoIP telephony. An advanced IP phone, the D717 features a high-resolution colour display that is second to none in its price segment and also features a unique and innovative brightness and proximity sensor.
The sensor reacts as soon as the user's hand nears the display or the function keys of the IP phone and then displays frequently used features and called numbers. In addition, the sensor ensures that the brightness of the telephone display is always adjusted to the current lighting conditions in the room, reducing the carbon footprint of each device.
In addition to the high-resolution colour display, the phone also has multi-colour LED function keys, an integrated gigabit switch and a USB port ensuring that the complete range of connectivity options are available.
Features
• 4-line blacklit B/W display (128 x 48 pixels)
• 5 programmable LED function keys
• Up to 4 SIP identities
• 2-port Gigabit Ethernet Switch, PoE
• Handling up to 4 simultaneous calls
• Dual Stack IPv4 / IPv6
| Specifications | ||
| Features | 6 SIP identities / accounts | |
| XML browser | ||
| Call lists for dialed, received, missed calls | ||
| Local directory with 1000 entries | ||
| Multiple language support | ||
| DTMF in-band / out-of-band / SIP-INFO | ||
| Interoperable with all major IP PBX platforms | ||
| Call Features | Speed dialing | |
| URL dialing | ||
| Local dial plan | ||
| Automatic redial on busy | ||
| Call completion (busy/unreachable)(2) | ||
| Caller identification | ||
| Call waiting | ||
| Call blocking (deny list) | ||
| Auto answer | ||
| Hold | ||
| Music on hold | ||
| Blind and attended transfer | ||
| Call forwarding | ||
| 3-way conferencing on the phone | ||
| Extension monitoring, call pickup | ||
| Call park, call unpark | ||
| Multicast paging | ||
| DND mode (do not disturb) | ||
| Keyboard lock | ||
| Client matter code (CMC) | ||
| Unified Communications ready | ||
| Audio | Codecs | G.711 A-law, µ-law |
| G.722 (wideband) | ||
| G.726, G.729AB, GSM 6.10 (FR) | ||
| Built-in assignable ringtones | ||
| Comfort Noise Generator (CNG) | ||
| Voice Activity Detection (VAD) | ||
| Setup | Configurable through web interface | |
| Provisioning | Automatic loading of settings via HTTP/HTTPS/TFTP | |
| DHCP Options 66/67 | ||
| Snom Redirection Service | ||
| Remote management via TR-069 / TR-111 | ||
| Protocols | SIP (RFC3261) | |
| DHCP, NTP | ||
| HTTP / HTTPS / TFTP | ||
| LDAP (Directory) | ||
| Dual Stack IPv4 / IPv6 | ||
| User Interface | Localization (language, time, dial tone) | |
| Red LED for call indication / message waiting | ||
| 4 context-sensitive keys | ||
| 3 programmable line / function keys with multicolour LEDs | ||
| Dedicated keys for | Message, DND, Directory, Menu, Transfer, Hold, Page | |
| Audio keys with LED indication | Mute, Speakerphone, Headset | |
| Volume key | ||
| 5-way navigation key | ||
| OK and Cancel keys | ||
| Automatic backlight enabled | ||
| Security | 802.1X authentication and EAPOL | |
| Transport layer security (TLS) | ||
| SRTP (RFC3711), SIPS, RTCP | ||
| HTTPS server/client | ||
| password-protected web interface | ||
| VPN-support | ||
| VLAN (IEEE 802.1Q) | ||
| LLDP-MED, RTCP-XR | ||
| Phone Features | Dimensions (approx.) | 205 x 185 x 40 mm (LxWxD) w/o foot stand |
| 205 x 185 x 200/220 mm (LxWxD) with foot stand | ||
| Weight (approx.) | device 710g, footstand 120g | |
| Input voltage | 5Vdc (SELV) | |
| Power supply | PoE or 5Vdc power adapter(1), 10 Watts | |
| Handset | 4P4C | |
| Headset | 4P4C | |
| Hearing-aid compatible (HAC) handset | ||
| 1 x USB 2.0 host port, Type A | ||
| Environmental conditions | Ambient temperature: 0°C to 35°C (32°F to 95°F) Storage temperature: -10°C to 45°C (14°F to 113°F) Humidity: 5% to 95% (non-condensing) |
|
| · Included in delivery | Phone unit Footstand Handset with cord Ethernet cable Quick Start Guide |
|
| Colour | black or white | |
| Type Approvals | CE Mark | |
| Safety IEC 60950 | ||
