Κατόπιν παραγγελίας
NeoGate TG400 - VoIP GSM Gateway(VoIP-GSM) - 4 GSM ports, 32SIP trunks
967.20€
1289.60€
Description
Yeastar TG400 is a compact 4 channels VoIP GSM/CDMA/UMTS gateway that connects GSM/CDMA/UMTS network with VoIP. Top Quality and Reliability Rich functionalities A robust feature set that fulfills your various needs and cuts communication cost Easy management Simple and intuitive Web-based configuration saves you loads of time Reliable performance Stable with advanced hardware and software architecture Excellent interoperability Interoperable with a broad list of softswitch, PBX, and IP-PBX like Elastix and Lync Server
| Key Features | ||
| 1 Stage/2 Stage Dial | SIP Peer Mode: Support | Gain Adjustment |
| Call Back | SIP server for IP phones: Support | Hotline |
| Call Duration Limitation | SMS Center | IP Blocklist |
| Call Status Display | System Logs | NTP |
| Carrier Selection: Auto/Manual | VoIP Trunk Group | Packet Capture |
| Firmware upgrade by HTTP/TFTP | Block List | Real Open API Protocol (Based on Asterisk) |
| GSM/CDMA/UMTS Ports Group Manage | Balance Alarm | Session Timer |
| Incoming /Outgoing Routing rules | Call Detail Record (CDR) | SIP Response Code Switch |
| Network Attack Alert | Call Progress Tone Generation | SIP Trunk: Support |
| Open API for SMS and USSD | Call Transfer | SMS Sending and Receiving |
| PIN Modify | Caller ID/CLIR | USSD |
| Send Bulk SMS | Configure backup/restore | Web based configuration |
| Specifications | |
| Number of Ports | 4 |
| GSM Frequency** | 850/900/1800/1900 MHz |
| WCDMA Frequency** | 850/1900 MHz, 850/2100 MHz, 900/2100 MHz |
| 4G Data | – |
| 4G LTE Band** | Depending on the module type. Check the supported band and operators. |
| Protocol | SIP, IAX2 |
| Antenna Splitter (4 in 1) | Support |
| Transport | UDP, TCP, TLS, SRTP |
| Voice Codec | G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex |
| DTMF Mode | RFC2833, SIP Info, In-band |
| Echo Cancellation | ITU-T G.168 LEC |
| Calling Type | Termination (VoIP to GSM/WCDMA), Origination (GSM/WCDMA to VoIP) |
| Network Protocol | FTP, TFTP, HTTP, SSH |
| LAN | 1 10/100 Mbps Ethernet Interface |
| NAT Traversal | Static NAT, STUN |
| Network | DHCP, DDNS, Firewall, OpenVPN, Static IP, QoS, Static Route, VLAN |
| Operation Range | 0°C to 40°C, 32°F to 104°F |
| Power Supply | AC 100-240V |
| Storage Range | -20°C to 65°C, -4°F to 149°F |
| Dimensions (mm) | 213 x 160 x 44 |
| Humidity | 10-90% non-condensing |
