NeoGate TA1600 - Analog VoIP Gateway - 16 FXS ports
771.90€
1029.20€
Yeastar NeoGate TA1600
The Yeastar NeoGate TA1600 is a multi-port FXS gateway including 16 FXS ports, line echo cancellation and is compatible with both SIP and IAX2. The TA1600 is ideal for small and medium enterprises that wish to integrate a traditional phone system into IP-based system.
Yeastar NeoGate TA1600 Features and Functions:
Fully compliant with SIP and IAX2
Flexible calling rules
Reliable fax performance with T.38
Provides high-quality voice compression with industry standard codecs
Line echo cancellation for 32, 64 or 128 ms echo delays
Web-based GUI for easy configuration and management
Excellent interoperability with a wide range of legacy and IP equipment
| Specifications | ||
| Interfaces | Ports | 16 FXS Ports |
| Telephony Interfaces | RJ11 and RJ21 50-pin Telco Connectors | |
| Network Interfaces | 1 10/100BASE-T Ethernet | |
| Indicators | Ports Status and Activity LEDs | |
| Media Processing | Protocol | SIP (RFC3261), IAX2 |
| Transport | UDP, TCP, TLS, SRTP | |
| Codec | G.711 (alaw/ulaw), G.722, G.723, G.726, G.729A/B, GSM, ADPCM | |
| Voice Capability | ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer, VAD, CNG, PLC | |
| DTMF Mode | RFC2833, SIP Info, In-band | |
| Fax | T.38 and Pass-through | |
| QoS | DiffServ, ToS, 802.1 P/Q VLAN tagging | |
| Telephony Features | Call Handling | 3-way Conference, Attended and Blind Transfer, Call Forward, Caller ID Display, Call Waiting, CDR, Direct Caller ID Calling, Distinctive Ringtone, Do Not Disturb, Flexible Dialing Plan, Hunting Groups, Hotline, MWI, Speed Dial |
| Security/ IP Services | Firewall | Built-in Firewall, IP Blacklist, Attack Alert |
| Network | DHCP, DDNS, OpenVPN, Static Route, VLAN | |
| Nat Traversal | Static NAT, STUN | |
| Network Protocol | FTP, TFTP, HTTP, HTTPS, SSH | |
| Management | Protocol | SNMP, RADIUS, TR-069 |
| Provisioning | Web GUI, Auto Provisioning, Backup and Restore, Firmware Upgrade by HTTP/TFTP | |
| Configuration | Remote Management, Packet Capture, System Logs, Voice Menu for FXS Gateways Basic Configuration, API | |
| Connectivity | Signaling | FXS Loop Start, FXS Kewl Start |
| Caller ID | BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based CID | |
| Disconnect Methods | Busy Tone, Polarity Reversal | |
| Short & Long Haul | 3REN, up to 1.5 km on 24 AWG wire | |
| Physical | Power | AC 100-240V (12V 5A) |
| Dimensions (L × W × H) (mm) | 440 × 250 × 44 | |
| Operation Temperature | 0°C to 45°C, 32°F to 113°F | |
| Storage Temperature | -20°C to 65°C, -4°F to 149°F | |
| Humidity | 10-90% non-condensing | |
| Mounting | Desktop, Rack-mount | |
| Compatibility | Softswitch and IP-PBX | Interoperable with 3CX, Asterisk, Lync Server, FreePBX and certified with Elastix and BroadSoft |
