Neogate TE200 - VoIP PRI Gateway (PRI-VoIP) - 2 PRI E1/T1 ports
2046.00€
2728.00€
Description
TE200 is a dual-port VoIP E1/T1/J1 gateway (VoIP to E1/T1/J1, and E1/T1/J1 to VoIP) that supports up to 60 concurrent calls. TE200 offers SMBs cost effective additions to a legacy telephone system to bring the true benefits of VoIP.
Key Features
- Blocklist
- Call Duration Limitation
- Caller ID Prefix
- Call Routing Rules
- E1/T1/J1 Diagnostics
- Firmware Upgrade by HTTP/TFTP
- NAT Traversal
- T.38 fax
- SIP Trunk Support
- SIP Registrar for IP phones
- Web-based Configuration
- Call Detail Record (CDR)
- Caller ID
- Configure backup/restore
- Custom Prompts
- Firewall
- IP Blocklist
- Packet Capture Tool
- Trunk Group
- SIP Peer Mode
- System Logs
| Specifications | |
| E1/T1/J1 Ports (Support PRI, E&M) | 2 |
| Protocol | SIP (RFC3261) |
| Transport Protocol | UDP, TCP, TLS, SRTP |
| Codec | G.711 (alaw/ulaw), G.722, G.726, G.729A, GSM, ADPCM, Speex |
| Echo Cancellation | ITU-T G.168 LEC Echo Cancellation, Dynamic Jitter Buffer |
| DTMF Mode | RFC2833, SIP Info, In-band |
| Network | DDNS, Firewall, PPPoE, Static IP, QoS, Static Route |
| Network Protocol | FTP, TFTP, HTTP, HTTPS, SSH |
| PRI switch types | Euro ISDN, nation, Q.SIG |
| Caller ID | BELL202, ETSI (V23), NTT (V23-Japan), and DTMF-based CID |
| LAN | 1 10/100/1000Mbps |
| WAN | 1 10/100/1000Mbps |
| Power Supply | AC 100-240V (12V 2A) |
| Dimensions (L × W × H) (mm) | 213 x 160 x 44 |
| Operation Range | 0°C to 40°C, 32°F to 104°F; |
| Storage Range | -20°C to 65°C, -4°F to 149°F |
| Humidity | 10-90% non-condensing |
