Ruijie-Reyee RG-RAP52-OD Wi-Fi 5 AC1300 Dual-Band Outdoor Access Point

Highlights:

• AC1300 Wave 2 Outdoor Mesh Mini-size AP For Villa & Retail
• Bracket or Poles, Flexible Installation to Fit Multi-Scene
• Weatherproof - Rated as IP65, Consistent Protection, Stable Signal
• Detachable Antennas, Cover where you need specially
• Reyee Mesh, Standalone Portal, AI Roaming, Optimized Features for Street Business
• 3 Year Warranty

Specifications:

• Wi-Fi Standards:
  - Wi-Fi 5 (IEEE 802.11ac Wave 2)
  - Wi-Fi 4 (IEEE 802.11n)
  - IEEE 802.11a
  - IEEE 802.11b/g
• MIMO:
  - 2.4 GHz, 2×2 MIMO
  - 5 GHz, 2×2 MIMO
• Max. Data Rate:
  - 2.4 GHz: 400 Mbps
  - 5 GHz: 867 Mbps
• Max. Transmit Power CE EIRP:
  - 2.4 GHz to 2.4835 GHz ≤ 20 dBm
  - 5.150 GHz to 5.350 GHz ≤ 23 dBm
  - 5.470 GHz to 5.725 GHz ≤ 30 dBm
• Max Throughput:
  - Up to 400 Mbps at 2.4 GHz
  - Up to 867 Mbps at 5 GHz
  - 1.267 Gbps per AP
• IP (Ingress Protection) Rating: IP65
• MTBF: > 400,000 hours
• Operating Mode: AP mode and routing mode

WLAN:

• Maximum number of clients: 110
• Recommended number of clients: 96
• Up to 8 SSIDs
• Supports SSID hiding
• Configuring the authentication mode encryption mechanism
• VLAN attributes for each SSID
• Supports Layer 2 user isolation
• KV Roaming
• Layer 2 Roaming
• Layer 3 Roaming

Security:

• SSID-based and radio-based STA limit
• Supports PSK authentication
• Black List / White List:
  - Maximum 256 rules per SSID
  - Maximum 1024 rules per AP
• WPA (TKIP), WPA2 (AES) and WPA-PSK data encryption
• Standalone Portal

Routing:

• Supports static IP address, DHCP, PPPoE Dial Up

Management & maintenance:

• Unified networking of all network equipment
• Local or remote management with Ruijie Cloud app
• Local management with web
• Remote management with Ruijie Cloud platform
• Platform management features:
  - WIO2.0, Automatic RF adjustment via the platform
  - Unified configuration via the platform
  - Unified monitoring via the platform
• AP Mesh:
  - Mesh management
  - Reyee Mesh

Fixed Ports:

• 1× 10/100/1000 Base-T port

LEDs:

• 1× system LED

Power Supply:

• IEEE 802.3af standard PoE power supply
• 24 V passive PoE power supply
• Max. Power Consumption: ≤ 14 W

Environmental:

• Operating Temperature: -30°C to 70°C
• Storage Temperature: -40°C to 75°C
• Operating Humidity: 10% to 95% RH (non-condensing)
• Storage Humidity: 10% to 95% RH (non-condensing)
• Installation: Wall mounting and pole mounting

Dimensions:

• Unit dimensions: 220 × 50 × 35.7 mm (excluding mounting bracket and antenna)
• Antenna size: 185mm
• Unit weight: ≤ 0.4 kg

Package Contents:

• RG-RAP52-OD Access Point
• 2x Antennaa
• 2x Band Clamps
• 1x Mounting Bracket
• 1x Screw Kit (Containing 2x 3.5 mm × 25 mm Expansion Screws and 2x Wall Anchors)
• 1x Warranty Card
• 1x Quick Installation Guide
